| Maximum continuous voltage (DC) | U꜀ | 7V | 16V | 34V | 65V | 8V | 7V | 34V |
| Maximum continuous voltage (AC) | U꜀ | 5V | 11V | 24V | 46V | 6V | 5V | – |
| Maximum discharge current (8/20μs) | Iₘₐₓ | 5kA per line (10kA common mode) | | | | | | |
| Maximum impulse current (10/350μs) | Iᵢₘₚ | 1.25kA per line (2.5kA common mode) | | | | | | |
| Impulse durability | | C2 8/20μs 5kA – D1 10/350μs 2.5kA | | | | | | |
| Maximum load current | IL | 250mA | 250mA | 250mA | 250mA | 250mA | 250mA | 250mA |
| L-L Voltage protection level @ 1 kV/μs | Uₚ | 15V | 30V | 40V | 80 V | 15V | 15V | 40V |
| L-PE Voltage protection level @ 1 kV/μs | Uₚ | 350V | 350V | 350V | 350V | 350V | 350V | 350V |
| Line resistance | | 3.9 Ω | 3.9 Ω | 3.9 Ω | 3.9 Ω | 3.9 Ω | 3.9 Ω | 3.9 Ω |
| Earth Isolation Versions | | -EC90 | | | | | | |
| Dimensions | 📐 | W 7mm X H 102mm X D 68mm | | | | | | |
| Weight | 📦 | 35g | | | | | | |
| Product Datasheet | PDF | SL7v5 | SL18 | SL36 | SL68 | SL485 | SL-RTD | SL420 |
